Rectangular Steel HSS Tube

Rectangular HSS is often used within welded steel frames where loading occurs from multiple directions. The flat shape makes rectangular HSS ideal for construction. It is often used to create a pleasing aesthetic effect.

Commodity name： Rectangular Steel HSS Tube

Category:

Steel HSS Tubes

Email: make@shoukunmetal.com Whatsapp: +86-19963513460

Rectangular Steel HSS Tube Description

Hollow Structural Sections (HSS) are often used in industrial building, construction, and infrastructure applications. HSS meets ASTM A500 or ASTM A1085 specifications to be used in the United States. This steel tube is a sustainable and highly efficient option with a higher strength-to-weight ratio than wide-flange sections, giving your construction more support with a smaller, lighter-weight footprint.

Product Parameters

External Size in Inches	Wall Thickness in Inches	Weight Per Foot
1 1/2 x 3/4	0.063	0.94
2 x 1	0.063	1.27
	0.100	1.82
	0.125	2.21
	0.188	3.05
2 1/2 x 1 1/2	0.125	3.06
3 x 1	0.125	3.06
3 x 1 1/2	0.125	3.48
3 x 1 1/2	0.188	4.96
3 x 2	0.125	3.91
	0.188	5.61
	0.250	7.11
4 x 2	0.125	4.76
	0.188	6.89
	0.250	8.81
	0.313	10.57
4 x 3	0.125	5.61
	0.188	8.17
	0.250	10.51
	0.313	12.69
	0.375	14.71
5 x 2	0.125	5.61
	0.188	8.17
	0.250	10.51
	0.313	12.69
	0.375	14.71
5 x 2 1/2	0.188	8.80
5 x 3	0.125	6.46
	0.188	9.45
	0.250	12.21
	0.313	14.82
	0.375	17.27
6 x 2	0.125	6.46
	0.150	7.66
	0.188	9.42
	0.250	12.21
	0.313	14.82
	0.375	17.26
6 x 3	0.125	7.31
	0.188	10.70
	0.250	13.91
	0.313	16.95
	0.375	19.82
6 x 4	0.188	12.00
	0.250	15.62
	0.313	19.08
	0.375	22.37
	0.500	28.43
7 x 4	0.188	13.25
	0.250	17.31
	0.313	21.20
	0.375	24.92

External Size in Inches	Wall Thickness in Inches	Weight Per Foot
7 x 5	0.188	14.52
	0.250	19.01
	0.313	23.33
	0.375	27.47
	0.500	35.22
8 x 2	0.188	12.00
8 x 2	0.250	15.62
8 x 3	0.188	13.28
	0.250	17.32
	0.375	24.93
8 x 4	0.188	14.56
	0.250	19.02
	0.313	23.33
	0.375	27.48
	0.500	35.22
9 x 7	0.250	25.83
9 x 7	0.375	37.69
10 x 4	0.375	35.58
	0.188	17.08
	0.250	22.42
	0.313	27.58
	0.375	32.57
	0.500	42.03
10 x 6	0.188	19.63
	0.250	25.82
	0.313	31.84
	0.375	37.68
	0.500	48.83
10 x 8	0.250	29.22
	0.313	36.09
	0.375	42.78
	0.500	55.64
12 x 4	0.250	25.82
	0.313	31.84
	0.375	37.68
	0.500	48.83
12 x 6	0.250	29.22
	0.313	36.09
	0.375	42.78
	0.500	55.64
12 x 8	0.250	32.63
	0.313	40.35
	0.375	47.89
	0.500	62.45
16 x 8	0.375	58.10

Application of Rectangular Steel HSS Tube

● Buildings
● Bridges
● Towers
● Sign supports
● Drilling platforms
● And other critical infrastructure.
